China Plastic Engine Oil Bottle Cap Chemical Barrel Drum Cap Mould Facotry

China Plastic Engine Oil Bottle Cap Chemical Barrel Drum Cap Mould Facotry

Mould Features

We can design and produce all kinds of plastic cap moulds according to customers' requirements. After many years' development and innovation, hot runner arts and crafts which is the most ideal in the line of the injection, is applied in making cap moulds. It reduces the product cost, raises the product quality, so it can produce automatically.

Hot Runner Cap Mould has following strong points:

1. Adopted temperature controller. Temperature of the cap is controlled point by point.

2. The material of core made of H13 and cavity are made of S136 stainless steel. Other parts are made of #P20 steel.

Our Solutions

We are ready and equipped to serve various types of plastic cap mould needs including motor oil shell mould, laundry detergent lid mould and some big jar cover molds for candy & biscuit. As a one stop plastic cap mould solutions provider, we have the ability to provide solutions from start to finish - idea generation, product design, mock ups, mould making, production to decoration.

We always focus on perfection on quality and services of plastic molding. We would like to supply our best services and our best plastic mould to all customers.


20L Engine Oil Can Bucket Flex EVA Pull up Spout Cap Mold Factory.

Injection Mould Name Plastic cap mould
Mould Core and Cavity Metal S136
Injection Machine Size 200tons
Demould Type Automatic
Metal Hardness  HRC 42-52
Mould Base Self-Made LKM DME
Mould Runner  Cold Runner &Hot Runner
Cavity Number Multi Cavity
Cycle Time 16 Seconds
Tooling Lead Time 60 Days
Mould Life 100-300 million shots/ 5-6years.Even in 10 years in good condition.
Mould Surface Treatment EDM,Texture Mirror Polishing
The main mould metal material and hardness for your reference,You can choose it for your injection mould.
Steel Model S50c P20 718H 2738H H13 2344 S136
Hardness(HRC) 17-22 28-32 33-38 36-40 48-50 48-52 42-52
