PP/PE Mineral Water Beverage Bottle Cap Mould
What are the advantages of plastic bottle cap mold and the factors to be considered in design?
Water Bottle Cap Injection Mold Mould Material:S136H(7075Aluminum,Becu, 45#, 50#, P20, H13, 718, 2738, NAK80, , SKD61 etc can be option) Plastic Material:PP,PC,PE,ABS,PVC,PET,AS.etc. Surface Treatment:Sandblast(Polishing/Texturing Can Be Customized) Mould Base:MISUMI,LKM,DME,HASCO,Self-Made.etc. Mould Warranty:2 Years Or 3 Million Shots Whichever Come First
Each PET bottle has a suitable plastic cap and a suitable cap enhances the appearance of the bottle. We provide our customers with high quality hot runner & cold runner cap injection molds and flip molds to create the ideal plastic caps. In our product list you can find the corresponding molds for making various caps, such as the general screw cap, safety anti-theft cap, pop-up cap and so on. These caps are suitable for use in mineral water bottles, soft drink bottles, juice bottles, as well as some food and non-food packaging containers.
Shuanghao plastic bottle cap mold is made with high quality international standard, and with very competitive price in the plastic cap Compression Moulding Machine industry, With efficient management team and technical innovation team, jeepine’s water bottle cap mold becomes more and more popular, As the only one public listed cap compression moulding technology company,jeepine plastic bottle cap molding system is the best choice of long term business partner in the world now.
Mould name | Mineral water cap mould |
Mould cavity | 8 cavity , 12 cavity ,16 cavity , 24cavity , 32cavity , 48cavity , according to machine size or customer’s request |
Insert material | Cavity : S136, Hardness :47-50° ; Core:H13 ,Hardness 47-50 °; Core surface need nitriding or QPQ treatment ，It is according to the mould parts hardness request ,after treatment the surface hardness around 60-90 ° |
Mould plate material | P20 718 S136 according to client’s request |
Runner type | Cold runner / hot runner , according to client’s request |
Hot runner system | The temperature difference under controlling within1℃difference it makes sure that the raw material cannt be burnt inside of hot runner.the wastage will be kept less than 1% .
|
Cap neck size | 3025,2925,38mm ….. |
Cap type | Different kind of anti-theft type cap |
Mould name | Beverage cap mould |
Mould cavity | 18 cavity , 12 cavity ,16 cavity , 24cavity , 32cavity , 48cavity , according to machine size or customer’s request |
Insert material | Cavity : S136, Hardness :47-50° ; Core:H13 ,Hardness 47-50 °; Core surface need nitriding or QPQ treatment ，It is according to the mould parts hardness request ,after treatment the surface hardness around 60-90 ° |
Mould plate material | P20 718 S136 according to client’s request |
Runner type | Cold runner / hot runner , according to client’s request |
Hot runner system | The temperature difference under controlling within1℃difference it makes sure that the raw material cannt be burnt inside of hot runner.the wastage will be kept less than 1% . |
Cap neck size | PCO1810, 1881, ALCOA1716 …. |
Cap type | Different kind of anti-theft type cap |
